Mechanical Eccentric Press Machine TAB-ECP63

Available! Contact us for a Quote

-

Out of stock

Detailed product description

TAB‑ECP63 is a mechanical eccentric press for heavy forming, cutting, and punching operations with a nominal capacity of 630 kN (about 63 tons), suitable for medium and heavy sheet‑metal production.​

It features a 100 mm slide stroke at up to 50 strokes per minute, a shut height of 270 mm adjustable by 80 mm, and 230 mm distance from slide center to frame for handling a wide range of parts.​

The die shank diameter is 50 mm with 70 mm hole depth, 370 mm distance between uprights, and 220 mm die height, providing flexibility for multi‑stage tooling.​

The table size is 450 mm front‑to‑back and 700 mm left‑to‑right, driven by a 5.5 kW motor, with approximate overall dimensions of 1800×1500×2650 mm to ensure high stability in industrial environments.​

Technical specifications

Model: TAB‑ECP63

Nominal capacity: 630 kN

Slide stroke: 100 mm

Strokes per minute: 50

Shut height: 270 mm

Shut‑height adjustment: 80 mm

Distance from slide center to frame: 230 mm

Die shank diameter: 50 mm

Die shank hole depth: 70 mm

Table size (front–back): 450 mm

Table size (left–right): 700 mm

Distance between uprights: 370 mm

Die height: 220 mm

Motor power: 5.5 kW

Overall dimensions: approx. 1800×1500×2650 mm​
