Mechanical Eccentric Press Machine TAB-ECP25

21,700

Out of stock

Detailed product description

TAB‑ECP25 is a mechanical eccentric press for medium‑duty forming, cutting, and punching operations with a nominal capacity of 250 kN (about 25 tons), suitable for production lines and industrial workshops.​

It features a 70 mm slide stroke at speeds up to 40 strokes per minute, a closed height of 200 mm with 60 mm adjustment range, and 180 mm distance from slide center to the press frame.​

The press has a 40 mm ram (tool shank) diameter with 70 mm shank hole depth, 160 mm column spacing, and a 170 mm‑thick work table for high rigidity during punching.​

Table size is 520 mm front‑to‑back and 330 mm left‑to‑right, driven by a 2.2 kW motor, with approximate overall dimensions of 910 mm depth, 700 mm width, and 1800 mm height.​

Technical specifications

Model: TAB‑ECP25

Nominal capacity: 250 kN

Slide stroke: 70 mm

Strokes per minute: 40

Closed height: 200 mm

Closed‑height adjustment: 60 mm

Distance from slide center to frame: 180 mm

Tool shank diameter: 40 mm

Tool shank hole depth: 70 mm

Table size (front–back): 520 mm

Table size (left–right): 330 mm

Column spacing: 160 mm

Work table thickness: 170 mm

Motor power: 2.2 kW

Overall dimensions: approx. 910×700×1800 mm​

Keywords

Mechanical eccentric press

TAB‑ECP25

25‑ton press

Sheet‑metal forming press

Shearing and punching press

Metal‑fabrication workshop equipment

25‑ton press machine

Eccentric press

Metalworking shop press

SKU 116
Product Category Eccentric Press
Weight 1 KG
